Bramidan X25 Commercial Level Cardboard Box Vertical Baler 208/230/480 Volt 3 Phase


Price: Call Toll-Free (800) 203-0233 for Pricing

Availability: In Stock - Call for Price

We Will Meet or Beat Any Price - Click Here to Submit Your Pricing Information

Part Number: X25   Brand Name:Bramidan   Manufacturer Part Number: X25

The superior press force paired with specially designed internal cross cylinders allow for stable compaction of material with a heavy bale weight.

Suggested Uses:

  • Farms and Food Production
  • Packaging
  • Manufacturing
  • Multi materials
  • Universities
  • Optimized for locations with space restrictions
    Fits in tight spaces with low ceilings. Very low height due to the cylinders being placed inside the machine.

    Very heavy bale weight
    The long stroke and exceptional press force allow the X25 HD to produce heavy bales.

    X25 HD - Heavy-duty baler for waste compaction::

  • Handles diverse types of materials
  • High volume chamber
  • Retainer dogs prevent material from expanding
  • Efficient and fast cycle time
  • No openings or moving parts on outside of machine
  • Low overall height (<6.5 feet)
  • Bale Size:
    30" depth x 48" width x 30" height
    Feed Opening:
    20" width x 20" height
    Depth:
    50"
    Width:
    69"
    Height:
    79"
    Weight:
    3150 pounds
    Acceptable Material:
    Aluminum Cans, Cardboard, EPS, Paper, PET Bottles, Plastic Foil, Plastic Hard, Textile, Tin cans
    Bale Eject:
    Automatic
    Bale Weight (Cardboard):
    500-650 pounds
    Bale Weight (Plastic Foil):
    550-775 pounds
    Full Bale Light:
    Yes
    Number of Ties:
    4 Ties
    Press Force:
    55,200 pounds
    Stroke:
    37"
    Type of tying:
    Twine/Steel Wire
    Cycle Time:
    23 seconds
    Electrical:
    208V, 230V or 480V, 3 Phase, 60 hz
    Motor:
    5.5 horsepower
    Noise Level (dB):
    59-60 dB
